SYM GANTRY CRANE
Item# | LTEP0040 |
Brand Name | SYM |
Hoisting Capacity | 100 ton |
Span | 7.5-22.5s |
Lifting Height | 6-30m |
Power Source | 50HZ-380V |
Width of Track | 37-70mm |
Wheel Diameter | ϕ 270 |
Moving Speed(Ground Control | Cabin Control) | 20-45 | 45-75 m/min |
Lifting Speed | 8 8/0.8 m/min |
Maximum Wheel Pressure of Crane(GroundControl/Cabin Control) | (1.08 - 1.54/1.38-2.84) TON |
Total Weight of Crane(GroundControl/Cabin Control) | (1.65 - 3.41/2.05-3.81) TON |
